Features and Functions

- 1-Channel, Class-AB, High-End Amplifier
- Signal to noise ratio of over 103dB
- High Quality Bipolar-input Dual OP
- High Quality/Transition Frequency Transistors
- High-precision 0.1% Output Resistors
- High density, Loss factor Input Capacitors
- Low internal resistance Power Capacitors
- Ultra Low On-Resistance, Fast Switching Mosfets
- High-power pure copper transformers
- Low Resistance Fuses

Technical Specifications

- Power RMS @ 4Ω: 1 x 320 watts
- Power RMS @ 2Ω: 1 x 550 watts
- THD @ Rated Power < 0.02%
- Signal to Noise Ratio > 102dB
- Frequency Response: 10Hz to 40,000Hz ±1dB
- Input Sensitivity: 0.5V to 8V
- Fuse Rating: 2 x 40A
- Overall Dimensions (mm): 210(W) x 62(H) x 416(L)

OPs Upgrading

The Reference amplifiers offer the possibility of replacing the original OPs (MUSES8820) with even higher performance OPs (MUSES02), or with other OPs the customer prefers. We recommend the operation to qualified technicians.
